BOSCH REXROTH
9510490089
$915.00
- BOSCH REXROTH
- Material:9510490089
- Model:AZPG-22-056RQC40MB GO2
Quantity in stock: 3
56 cm³/rev, Clockwise rotation, Straight keyed SAE J744 22-1 , SAE J744 101-2 (B) 2-bolt flange, SAE Split flange, UNC thread
The key task of external gear pumps is to convert mechanical energy (torque and rotational speed) into hydraulic energy (flow and pressure). To avoid unnecessarily high heat losses, units with high efficiencies are sought after. These are realized by means of pressure-dependent gap sealing and high-precision manufacturing technology.
Unpacked Weight: 10.900 kg
| Long service life |
| Slide bearings for high loads |
| Port connections: flanged or threaded |
| Consistent high quality based on large-volume production |
| Drive shafts according to ISO or SAE and customer specific solutions |
| Offer Drawing | Download Offer Drawing |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Manual | Download Manual |
| Rear cover | Standard |
| Maximum rotational speed | 2300 |
| Productgroup ID | 7,21,22,23,24,25 |
| Size (geometric displacement) | 56 |
| Sealing material | NBR |
| Version | Corrosion resistant, pinned |
| Noise level | Standard noise level |
| External gear unit | External Gear Unit |
| Application | general |
| Drive shaft | Straight keyed SAE J744 22-1 |
| Housing material | Aluminum |
| Line connection | SAE Split flange, UNC thread |
| Series | Model G (22.5 ... 56 cm³/rev) |
| Front cover | SAE J744 101-2 (B) 2-bolt flange |
| Maximum intermittent pressure | 200 |
| Direction of rotation | Clockwise rotation |
| Unit version | Bearing diameter 26 mm |
| External gear unit function | Pump |
| Weight | 10.900 |
| Max. flow | 128.8 |
